ZF04 Selector Valve with Ceramic Spool is small in size, easy to integrate into the instrument, wear-resistant, stable and reliable in operation, and can be used with matching syringes.
Core technology
1. Good stability, easy to crystallize flow path can be switched;
2. There is no liquid pulsation when switching the flow path, which effectively solves the problem of droplets and backflow at the outlet during micro injection;
3. The rotor material supports customization, which is more in line with user needs;
4. High pressure resistance, the maximum pressure resistance of the traditional three-way solenoid valve is 0.3MPa, and the maximum pressure resistance of this three-way valve is 0.68MPa, which can be stably switched when high pressure is output;
5. Widely used in various analysis industries, and can provide overall flow path solutions for different needs of customers.
| Valve Structure | Switch Type |
|---|---|
| No. of Channel | 2Port, 3Port YType, 4Port DType |
| Orifice Size | 1.5mm(Customized) |
| Port-to-Port Volume (Dead Volume) | 2ul |
| Wetted Material | PCTFE / Ceramic |
| Max. Water Pressure | 0~1.2Mpa |
| Max. Air Pressure | 0~1Mpa |
| Liquid Temperature | 0~100℃ |
| Connection | 1/4-28UNF |
| Head Material | PCTFE |
| Spool Material | PTFE, Sapphair, Ceramic |
| Trigger Signal | DC7V-33V |
| Feedback output signal | 3.3-24V High Low Level Output |
| Communication Interface | RS485/RS232 |
| Valve Drive | ≤500ms |
| Max. Power | 48W |
| Operating Temperature | -10℃~+60℃ |
| Power Supply | DC24V/2A |
| Dimension(L*W*H) | 42*42*113mm |
